Applications for Liquid Light Guides
* Rapid and controlled UV curing
* Remote inspection
* High intensity cold white light for endoscope illumination
* Fluorescence excitation for forensic work and crack detection
* Indoor illumination with natural sunlight
* Intense white light for microscopy and photography
* Side lit decorative or task lighting applications
| Type | Standard apertures (mm) | NA | Spectral Range (nm) | Applications |
| UV | 3, 5, 8, 10 | NA = 0.59
2a = 73 |
275 - 700 | Curing of inks, adhesives, coatings • fluorescence inspection • arc and tungsten halogen light sources • spectroscopy • solar |
| Visible | 3, 5, 8, 10 | NA = 0.59 2a = 73 |
300 - 980 | Medical / industrial endoscopy • illumination for photography, microscopy • arc and tungsten halogen light sources • spectroscopy |
